BLAUPUNKT HAMBURG SQM 23 DAB BLUETOOTH CAR RADIO

HAMBURG SQM 23 DAB
$795.00
Completely period-correct for classic cars of the 1980's, this popular installation was found in many European classic cars has now been revitalized with today's most popular features and technology!
SKU: BL-HASCM
  • Overview

Over the years, some models have developed into true cult objects. This also applies to the legendary Blaupunkt “Hamburg SQM 23” from 1983. Now we present the new interpretation of th popular 1-DIN car radio and combine the design of the 80s model with new technologies and functions. The result is the Blaupunkt “Hamburg SQM 23 DAB”.

Its operating concept, simple design and crystal-clear reception contributed significantly to the popularity of the original Hamburg car radio. For the new edition, we adopted the styling of the original model, but at the same time gave the radio modern multicolor lighting for the LC display. The key labels, which were then still illuminated with light bulbs, are now being replaced by modern and durable warm white LEDs. This lighting can also be activated via the vehicle lighting when the car radio is switched off.

Thanks to the Blaupunkt Codem FM RDS tuner and DAB+ digital tuner, first-class reception remains a strength of the new Youngtimer car radio. New are the multimedia interfaces for modern Apple® devices and USB mass storage media for playing music or charging mobile phones. The new model also supports Bluetooth® audio streaming from apps such as a music player or streaming service such as Spotify on the mobile phone.

With the help of the voice assistant on the mobile phone (such as Siri, Google or Alexa) the mobile phone can be accessed without having to pick it up. Of course, hands-free calling is also supported.

So that an audio source such as USB, Apple iPod or Bluetooth can be selected directly, a button on the device can be programmed via the menu to start your favorite source. The device settings are permanently saved, even if the battery is disconnected – even if this is no longer necessary thanks to the minimized standby power consumption to protect the battery.

The new “Hamburg SQM 23 DAB” has a short installation depth – ideal for classic cars with shortened installation shafts. But it’s not just the car radio itself that takes the user on a journey through time, the packaging of the device was also elaborately designed and modeled on the original.



Multicolour LCD and front USB

The display of the Hamburg SQM 23 DAB can be set in 7 different colors and thus adapted to the vehicle-specific cockpit lighting. One of the two USB ports is hidden behind the front flap. Short USB sticks can therefore visually disappear behind the flap to maintain the original look.
















SPECIFICATIONS


RADIO

  • High-End CODEM IV World-tuner
  • FM, AM, DAB, DAB+ Tuner with radiotext/ DLS
  • Traffic function
  • Alphabetical DAB+ List
  • Travelstore
  • Service following
  • Band Introscan



MEDIAPLAYER

  • USB (2x)
  • MP2, MP3, WMA, FLAC, M4A (AAC), APE, WAV support
  • Introscan
  • Repeat function
  • Mix function
  • Apple iPod Support



BLUETOOTH

  • Internal and external Microphone
  • Audiostreaming with track info
  • Voice assistant support (e.g. Siri, Google, Alexa)
  • Wake-up on call
  • Phonebook access



SOUND

  • Sound presets
  • Loudness
  • 4-channel pre-amp out+ Sub-out
  • 4x 50 Watt



GENERAL

  • Multicolour LCD (7 colors)
  • DIM- function
  • Night design if switched off (Buttons)
  • Favorite button for one source
  • Permanent memory
  • Short body (low installation depth)
  • IR-remote option (compatible to old RC-10 remote control)
  • SWC option (Steering Wheel Control)
